Connect the DAS: Enhanced cellular finally arrives at Wrigley Field

Cubs VP of IT Andrew McIntyre looks up at some new DAS antenna placements in the main level concourse. Credit all photos: Paul Kapustka, MSR (click on any picture for a larger image)

When it comes to sports fans and their beloved stadiums, change is sometimes hard to take, especially at historic venues like the Chicago Cubs’ beloved Wrigley Field.

The last ballpark in the major leagues to get lights (in 1988), fans of the iconic Wrigley with its ivy-covered outfield walls put up some fierce resistance to some of the latest changes brought to the ballpark by the team’s latest owners, the Ricketts family, ove the past few years. An expansion of the bleacher seats, some new video boards behind the stands in the outfield and construction of a hotel and office building adjacent to the stadium all had their naysayers, some of whom would still prefer the old to anything new.

But this season, Wrigley is finally unveiling a part of its renovation that everyone can get behind — better cellular connectivity inside the park thanks to a new neutral-host distributed antenna system (DAS) built by DAS Group Professionals (DGP) for the Cubs. Delayed a couple years from its originally planned deployment due to the Cubs’ World Series title run in 2016, the new system has contracts with all four of the major U.S. wireless carriers, and should help fans share more memories from the Friendly Confines in the seasons to come.

Success on the field makes waiting OK

Editor’s note: This profile is from our latest STADIUM TECH REPORT, an in-depth look at successful deployments of stadium technology. Included with this report is a profile of a new MatSing ball DAS deployment at Amalie Arena, a new under-seat DAS deployment for the San Francisco Giants at AT&T Park, and a look at the networks inside the new Banc of California Stadium in Los Angeles! DOWNLOAD YOUR FREE COPY now!

First announced in 2015, the plan to bring the new DAS as well as a new Wi-Fi network to Wrigley was pushed back until this season, mainly because of the Cubs’ new-found success on the field. In addition to the World Series title in 2016 — as everyone knows, the Cubs’ first in 108 years — the Cubs also went deep into the postseason in both 2015 and 2017, reaching the NLCS in both those years. As the extended seasons pushed back all kinds of renovation construction schedules, the arrival of the new connectivity options was pushed back a season longer than expected — a delay that was felt but perhaps not minded all too much by the celebrating Cubs fans.

DAS antennas visible near tops of stanchions in lower seating bowl

Since deployment of the DAS was (mostly) fairly straightforward — the DGP deployment uses entirely overhead and side-structure antenna placements, thanks to Wrigley’s multiple overhangs — it was finished in time for opening day. The Wi-Fi network, however, will be rolled out as the season progresses, mainly due to the need to place APs under seats in the lower seating sections.

Much of the engineering to get both systems inside the stadium faced more than the regular share of stadium conflicts, as this past offseason saw the Cubs pull out almost all the lower-bowl seats and dig 60 feet down into the dirt to clear room for some under-seat club areas, one of which is already open. Even though the DAS network wasn’t powered up until about a week before the season’s first pitch, deadlines were met and the new celluar system was ready for opening day.

“We definitely put scheduling and timing to the test, but we got it done,” said Andrew McIntyre, vice president of technology for the Chicago Cubs. “By the All-Star break, we should have both systems online,” McIntyre said.

The DAS system deployed by DGP uses JMA equipment, just like DGP’s other big-stadium DAS deployments at the San Francisco 49ers’ Levi’s Stadium and the Sacramento Kings’ Golden 1 Center. Steve Dutto, president of DGP, acknowledged the challenge of the Wrigley buildout, including one instance where DGP technicians needed to set up scaffolding to mount antennas but couldn’t because instead of a concrete floor there was a 60-foot hole in the ground.

“We worked around all that and got it done,” said Dutto.

New club spaces get new flat antennas

Mobile Sports Report traveled to Chicago for a mid-April visit, hoping to get some sense of the new network’s performance on a full-stadium game day. Instead, we got a lonely and chilly tour when sub-freezing temperatures caused that day’s game to be canceled. One positive was that with empty stands, it was easier to get around and see all the DAS antenna placements.

New flat-panel DAS antenna blends nicely in club space.

The first part of our tour was a trip underground to the new 1914 Club (for the year Wrigley opened) that sits directly under the seats right behind home plate. With the feel of sports bar-meets-speakeasy, the classy premium-seat space has great connectivity even while underground, thanks in part to a new flat-panel disc-shaped omnidirectional DAS antenna from Laird Technologies that DGP used in both indoor and outdoor placements.

With nobody in the club, we got an off-the-scale speedtest of 139 Mbps down and 46.7 Mbps up, proof on one level that the system is ready to go. Since it was freezing outside (did we mention it was cold?) MSR didn’t stop to take our gloves off to get many more tests, but we did get marks in the high 30 to high 40 Mbps range pretty much anywhere we did stop, including the upper decks and the bleachers. Even out in the middle of the adjacent plaza (where the Cubs’ networks are designed to cover) we got a DAS speed mark of 38.2 Mbps / 44.0 Mbps.

“The new DAS is much more higher performance grade than in the past,” McIntyre said.

The premium-seating club spaces, which were previously nonexistent at Wrigley, will expand next year when the Cubs finish out two more underground spaces, along each base line. According to McIntyre fans in those clubs will be able to watch players using the underground batting tunnels to tune their swings mid-game.

The last phase of the current Wrigley renovations will also see the addition of some more open gathering and club areas on the upper deck level, including party porches on the outside of the stadium walls overlooking the plaza (now called Gallagher Way under a sponsor-naming deal with the Illinois-based insurance brokerage). Gallagher Way, which hosted an outdoor ice rink in the winter, is set to hold concerts and other gatherings like movie nights this summer.

Old overhangs perfect for new technology

Sometimes in stadium wireless retrofits, you get lucky and the old stuff blends pretty well with the new. Take Wrigley Field’s classic metal-and-wood overhangs, which provide shade and rain cover for fans on the lower back and upper decks. According to DGP vice president of engineering Derek Cotton, getting DAS antennas in the right spots for a good signal there was half easy, half hard.

On the top levels, DGP was able to install the JMA gear out where it could offer the best connection — at the edge of the roofs, pointing backward toward the stands. With aesthetics a top concern at Wrigley, the roofs were a perfect place to “hide” some of the 420 total antennas in the deployment.

Green-painted DAS antennas point toward stands from back of bleachers club area

But on the lower-level roof, DGP and the Cubs had a concession to make that will be fixed during the upcoming offseason. Because of the deep pits dug into the box seat and field level, Cotton said DGP couldn’t get a scaffolding set to reach the outer parts of the lower roof — so instead DGP put those antennas in toward the backs of the roofs, and will move them out to the edges this winter. Some other antennas installed this year will have to be taken out and replaced while the rooftop party decks get built; and by next year the Cubs hope to have all the marooned gear from an AT&T Wi-Fi deployment from 2012 removed — but if you have sharp eyes this summer you can spot some of the old “Pringles can” Wi-Fi radios still nestled up in the rafters.

‘Creativity’ needed for bleachers

If DAS deployment in the main seats at Wrigley was fairly straightforward, for the venue’s unique and famous bleacher seating DGP’s Cotton said “some creativity was needed” to find places to mount antennas.

With no overhead structure and only the historic, manually operated scoreboard in the back, Wrigley’s bleacher seating now has DAS coverage from a wide array of antenna placements that took use of just about every kind of mounting area available. Some gear hangs from the back of a sponsor’s sign in left field; other antennas are tucked underneath the bottom of the scoreboard, pointing out from a small club area there; and still others are concealed in the tall grass of the planters that go up the sides of the centerfield seating section, just next to the poles that carry the Cubs’ World Championship flags from 1907, 1908, and most recently, 2016.

Other more normal antenna placements are found around the back side of the bleachers, where recent renovations added a concessions area and more stairways.

DGP’s Derek Cotton inside the Wrigley head end room

Moving outside the park to the plaza, artistic concealment continues with antennas hidden on light poles that surround the triangular plot of lawn. According to McIntyre, the club’s wireless coverage extends across Clark Street to the new Hotel Zachary, named for Wrigley Field’s original architect, Zachary Taylor Davis.

The hotel, which has retail shops on the street level — including a McDonald’s franchise that replaces a standalone McDonald’s that used to sit in the parking lot where the plaza now stands — has DAS coverage on all floors, with Wi-Fi planned for public spaces on the first floor and second floor, where the main lobby and lobby bar reside. In the lobby bar comfortable couches provide a great place to look over the plaza and at Wrigley; and in fact the Extreme Networks Wi-Fi gear visible on the ceilings is already operative there, though purposely limited in throughput to 7.5 Mbps up and down for now.

Most of all the wiring for the new networks comes together in a small brick headend building about a block north on Clark, behind the Wrigleyville hot dog stand. Unless you knew what was inside, you’d be hard pressed to guess why there are huge strands of red, white and blue cabling coming through one wall. Just before the start of the season, the Cubs announced a deal with Comcast Business that will see a “XfinityWiFi@Wrigley” label on the Wrigley Wi-Fi SSID. According to McIntyre Comcast will bring in twin 10-Gbps pipes to power the Wrigley Wi-Fi network.

When the Wi-Fi network comes online later this season, there will be even less of a reason to believe there will be any more grumbling about connectivity at the Friendly Confines. The new era starts with the DAS deployed by DGP, which was picked by McIntyre and the Cubs several years ago, after hearing of DGP’s deployments at Levi’s Stadium and over face-to-face meetings at the SEAT Conference.

And while Cubs fans didn’t have to wait for new wireless as long as they did for a world championship, they can now start enjoying the ability to connect to the world outside the ivy.

“When it’s fully done our fans will have a real ability to share, in a modern way, from one of the most iconic and historic venues,” McIntyre said. “It’s a whole new world.”

This look at the main seating shows the multiple overhangs where DAS antennas were mounted

This look at the Wrigley Field bleachers shows the lack of any structures to hang antennas from

If you get hungry while at the Wrigley Field head end, this fine dining establishment is just outside the door

“How often does the train come by?” “So often you don’t notice.”

Wrigley Field gets new DAS in time for Cubs’ home opener

The Chicago Cubs’ Wrigley Field will have a new DAS working for opening day. Credit for these 2017 season pictures: Paul Kapustka, MSR (click on any photo for a larger image)

After some construction delays that no Chicago Cubs fans minded, the Friendly Confines of Wrigley Field will have a new high-performance distributed antenna system (DAS) operational for Monday’s scheduled Cubs home opener for the 2018 season.

Designed and deployed by DAS Group Professionals, the new in-stadium cellular network was originally scheduled to be ready by last year; but when the Cubs took their historic march to the World Series title in 2016, many of the in-progress construction plans for Wrigley Field got delayed or rearranged, to the objection of nobody at all who cheers for the north siders.

And even though some of the most ambitious parts of the Wrigley renovation took place this winter — including removing most of the seats and concrete in the lower seating bowl to clear the way for some lower-level club spaces — the DGP crew along with the Cubs’ IT organization delivered the new cell network in time for the first pitches scheduled Monday afternoon.

Wi-Fi coming in as season goes on

“We definitely put scheduling and timing to the test, but we got it done,” said Andrew McIntyre, vice president of technology for the Chicago Cubs, in a phone interview. First announced back in 2015, the networking plan for the Wrigley renovations — which includes coverage for the plaza outside the stadium, the new team office building as well as the across-the-street Hotel Zachary that also just opened for business — also includes a new Wi-Fi network using gear from Extreme Networks. Since the Wi-Fi network is more construction-conflicted than the DAS deployment, it will be introduced gradually over the next few months, McIntyre said.

“By the All-Star break, we should have both systems online,” McIntyre said.

The DAS system deployed by DGP uses JMA equipment, just like DGP’s other big-stadium DAS deployments at the San Francisco 49ers’ Levi’s Stadium and the Sacramento Kings’ Golden 1 Center. Steve Dutto, president of DGP, acknowledged the challenge of the Wrigley buildout, including one instance where DGP technicians needed to set up scaffolding to mount antennas but couldn’t because instead of a concrete floor there was a 60-foot hole in the ground.

Hey hey!

“We worked around all that and got it done,” said Dutto. According to Dutto DGP has signed up all four major U.S. wireless carriers for the DAS, with all except Sprint operational for opening day. The head-end building for the DAS, he said, is located in what he thinks is a former hot-dog stand a half a block from the park. (If you’re looking for a snack in the head end room, just remember, in Chicago there’s no ketchup on hot dogs.)

Dutto said the DAS antennas are all overhead mounts, not a problem in Wrigley since the overhangs offer plenty of mounting spaces. However, given the historic look and feel of the park, Dutto did say that “we definitely had to tuck things away better and make sure we had good paint matches.” Not a Chicago native, Dutto said that the charm of the stadium hit him on first view.

“When we pulled up for the first time,” he said, “it was… wow. There’s nothing like it.”

Under seat for Wi-Fi will take time to deploy

The Cubs’ McIntyre, who admits to guzzling coffee by the quart these days, said the field-level renovations — which included removing all lower seats and the foundational concrete to clear out room for field-level club spaces — made finishing the Wi-Fi deployment something that couldn’t be pushed. With no overhangs covering the premium box seat areas, Wi-Fi APs there will need to be mounted under seats, something that just couldn’t get finished by Monday.

“It’s less of a technical challenge and more of a structural engineering challenge,” said McIntyre of the under-seat deployment method, which usually involves a lot of work with drilling through concrete and mounting APs in weather-sealed enclosures. McIntyre said the Cubs and Extreme also plan to use under-seat deployments in Wrigley’s famous outfield bleachers, which also lack any overhead infrastructure. In what he termed a “slow roll,” McIntyre said parts of the Wi-Fi network will come online gradually as the season progresses, starting first with the spaces outside the stadium.

Bringing backbone power to the new network is partner Comcast Business, which just announced a sponsorship deal with the Cubs that will see a “XfinityWiFi@Wrigley” label on the Wrigley Wi-Fi SSID. According to McIntyre Comcast will bring in twin 10-Gbps pipes to power the Wrigley Wi-Fi network.

This panoramic view shows why the lower level seats will need under-seat APs for Wi-fi

Connectivity at the core of Little Caesars Arena, District Detroit

Little Caesars Arena, the new home for the Detroit Red Wings and the Detroit Pistons. Credit: Olympia Entertainment (click on any photo for a larger image)

Bringing great wireless connectivity to a new stadium is almost table stakes these days. But building up a nearby commercial district — and keeping connectivity high outside the venue’s walls — is a bet of another level, especially in Detroit where networks extend outside the new Little Caesars Arena into the 50-block District Detroit.

Following the arena’s opening in September of 2017, the prognosis so far is so far, so good, with solid reports of high network performance on both Wi-Fi and cellular networks in and around the new home of the NHL’s Detroit Red Wings and the NBA’s Detroit Pistons. But for John King, vice president of IT and innovation for venue owners Olympia Entertainment, the responsibilities for him and his network team extend far beyond the new stadium’s walls.

“We’re focused on the [wireless] signal not just in the bowl, but also in the surrounding elements — the streets, the outdoor arenas, and the Little Caesars Arena garage,” said King in an interview shortly after the arena opened. “The vision is, to be connected wherever you are. And to share that experience.”

An ambitious revival in downtown Detroit

Editor’s note: This profile is from our most recent STADIUM TECH REPORT for Winter 2018, which is available for FREE DOWNLOAD from our site. This issue has an in-depth look at the wireless networks at U.S. Bank Stadium in Minneapolis, as well as profiles of network deployments at the Las Vegas Convention Center and Orlando City Stadium! DOWNLOAD YOUR FREE COPY today!

The inside concourse at Little Caesars Arena. Credit: Olympia Entertainment

Built nearby the Detroit Lions’ Ford Field and the Tigers’ Comerica Park, the new hoops/hockey stadium seats 19,515 for hockey and 20,491 for basketball. Unlike many stadiums of the past which rise up from the ground, Little Caesars Arena is built into the ground, 40 feet below street level. The innovations in construction and accessibility, including an outdoor arena adjacent to the indoor one, may require another full profile and an in-person visit. For now, we’ll concentrate on the wireless deployment in and around Little Caesars Arena, which was funded in part by a sponsorship from Comcast Business, which provides backbone bandwidth to the arena and the district in the form of two 100 Gbps connections. The Wi-Fi network design and deployment, done by AmpThink, uses Cisco Wi-Fi gear; Cisco’s Vision for Sports and Entertainment (formerly known as StadiumVision) is used to synchronize video output to the 1,500 TV screens located in and around the venue.

On the cellular side, Verizon Wireless built a neutral-host DAS, which was getting ready to welcome AT&T as the second carrier on board shortly after the opening. According to King, the Wi-Fi network has approximately 1,100 total APs both inside and outside the arena, many of those from Cisco’s 3802 series, which each have two radios per AP. For many of the 300 APs located in the main seating bowl, Little Caesars Arena went with an under-seat deployment, with some others placed in handrail enclosures, especially for the basketball floor-seating areas.

“AmpThink did a really nice job with the deployment,” said King, who said the arena’s open-air suite spaces helped provide “lots of flow” to wireless gear, without the historical overhangs around to block signals on different levels. One early visitor to the arena saw many Wi-Fi speed tests in the 50-60 Mbps range for both download and upload, as well as several in the 80-to-100 Mbps range, signs that a strong signal was available right at the start.

“We’ve still got a lot of tuning, but early on we’re getting great results,” said King of the Wi-Fi performance. “Our goal is to make it the best it can be.”

Staying connected outside the walls

Like The Battery area surrounding the Atlanta Braves’ new SunTrust Park, the District Detroit is meant to be a stay-and-play kind of space, with restaurants, clubs, office spaces and residences seeking to lure visitors and residents to do more than just see a game. For King and his team, one of their tasks is to ensure that visitors can stay connected no matter where they are inside the district, including inside restaurants, offices and other indoor spaces.

Connectivity blends well with the architecture inside Little Caesars Arena. Credit: Tod Caflisch, special to MSR

“We want the [network] signal to be robust, to carry into outdoor spaces, restaurants and many other areas” inside the District Detroit, King said. “We want to push the envelope a little bit and create a useful opportunity.”

Back inside Little Caesars Arena, the team and stadium apps are built by Venuetize, which built a similar integrated app for the Buffalo Bills and the Buffalo Sabres, one that also extends outside arenas to support connectivity in city areas. King said that Little Caesars Arena will be testing pre-order and express pickup concession ordering through the app, with a focus on seating areas that don’t have ready access to some of the club facilities.

Like any other new facility, Little Caesars Arena will no doubt go through some growing pains in its debut season, but for King and others who spent time getting the venue ready it’s fun to have the doors open.

“It’s really great seeing it all come to life,” King said.

Comcast Business to power Wi-Fi at Little Caesars Arena

Comcast Business has signed up as the Internet bandwidth provider for the soon-to-open Little Caesars Arena in Detroit, as part of an $11 million capital expenditure deal that will also bring assorted voice, video and other services to both the new arena and the surrounding “District Detroit.”

According to a press release from Comcast Business, the service provider will bring two 100-gig circuits of bandwidth to the arena, the new home of the NHL Detroit Red Wings and the NBA’s Detroit Pistons. Set to open on Sept. 12, the new venue will have more than 1,000 Wi-Fi APs in the arena and in “surrounding buildings and event spaces,” according to the Comcast release.

Comcast has a similar arrangement with the Atlanta Braves and their new home, SunTrust Park, as well as with the surrounding live/work environment there, called The Battery Atlanta. In a report in Crain’s Detroit Business, a Comcast exec said the Detroit deal was taking such sponsorships “A whole ‘nother step further,” adding that the District Detroit area is much bigger than the Battery’s footprint.
