New Report: Dickies Arena sets a new standard for arena excellence

MOBILE SPORTS REPORT is pleased to announce the Spring 2020 issue of our STADIUM TECH REPORT series, the ONLY in-depth publication created specifically for the stadium technology professional and the stadium technology marketplace.

Our latest issue contains an in-person report on the new Dickies Arena in Fort Worth, which may have just set the new standard for excellence in an arena experience. We also recap another record Wi-Fi day at Super Bowl LIV, as well as a DIY Wi-Fi network at Rutgers University.

You can READ THE REPORT right now in our new flip-page format, with no registration required!

For those who prefer the PDF, you can also download a copy of the report for free as well!

We’d like to take a quick moment to thank our sponsors, which for this issue include Corning, Boingo, MatSing, Cox Business/Hospitality Network, Comcast Business, Samsung, and American Tower. Their generous sponsorship makes it possible for us to offer this content free of charge to our readers. We’d also like to welcome readers from the Inside Towers community, who may have found their way here via our ongoing partnership with the excellent publication Inside Towers. We’d also like to thank the SEAT community for your continued interest and support.

Fiserv Forum’s wireless networks ready for the Democratic Convention

Milwaukee’s Fiserv Forum, home of the NBA’s Milwaukee Bucks and also the locale for this summer’s Democratic Convention. Credit all photos: Paul Kapustka, MSR (click on any picture for a larger image)

With one of the most demanding arena-sized events headed its way this upcoming summer, the wireless networks at Milwaukee’s Fiserv Forum appear to be more than ready to handle any audience demand for mobile connectivity.

With a full-featured distributed antenna system (DAS) deployed and operated by ExteNet Systems using gear from JMA Wireless, as well as a Wi-Fi network using Cisco gear, Fiserv Forum shows both the expertise of wireless providers who have a long history of knowing what works, as well as the foresight to add new techniques and technologies to combine high performance with the quality aesthetics that are the hallmark of the new home of the NBA’s Milwaukee Bucks.

And while a Mobile Sports Report visit this past fall for a Bucks game found all the wireless elements in top working order, the big event for the venue’s second year of operation will be the Democratic National Convention in July 2020. While the four-day nomination gathering is a test for any locale, Fiserv Forum’s forethought on how to prepare for numerous types of events in and around its uniquely designed structure has it well prepared to handle whatever wireless needs the convention will require.

It all starts with the DAS

Editor’s note: This profile is from our latest STADIUM TECH REPORT, which is available to read instantly online or as a free PDF download! Inside the issue are profiles of the new Wi-Fi deployment at the University of Oklahoma, as well as profiles of wireless deployments at Chase Center and the University of Florida! Start reading the issue now online or download a free copy!

Even in these days of predictions of the death of DAS, Fiserv Forum is proof that for high-profile venues, carriers will still participate in a quality deployment. And while many venues have just two or three cellular providers on their DAS, according to ExteNet, the Fiserv Forum DAS has five major carriers participating — AT&T, Verizon, T-Mobile, Sprint and U.S. Cellular.

Wi-Fi AP on an outdoor plaza light pole

Unlike some new arenas, where wireless is an afterthought to construction, ExteNet was involved early on, according to Manish Matta, vice president of marketing at Extenet.

“Getting in sooner rather than later is always better,” said Matta, who said ExteNet was well involved in the overall construction plans, ensuring that there were no delays associated with wireless deployments holding up construction of other parts of the building.

During a pregame tour in October with a team from ExteNet as well as with Robert Cordova, chief technology and strategy officer for the Bucks, Mobile Sports Report got an up-close look at some of the inside parts of the DAS network design, including the headend room and multiple antenna installations that were hard to find given their well-designed placements and camouflaging.

In addition to regular enclosures that were painted or otherwise placed in areas out of the main sight lines, ExteNet and JMA also utilized some of the newer circular flat-panel antenna enclosures that fit flush to ceilings, minimizing the exposure.

The 215 DAS antennas are powered by 40 remote units. According to JMA, the remotes are connected to the backbone with optical fiber, and use digital power to bring power to elements up to a mile away. With 16 sectors in the bowl design, the DAS is able to segment coverage to all parts of the arena, including the bowl as well as concourses and other in-house areas.

DAS antenna in a concourse location

ExteNet, which owns and operates the DAS as a neutral host, also installed 10 extra MatSing ball antennas in the rafters for additional top-down coverage. Though only AT&T is using the MatSings right now, ExteNet said they are integrated into the DAS design if other carriers should wish to utilize them in the future.

During a short walk-around before the Bucks game started, MSR got a DAS speedtest of 85.8 Mbps on the download and 14.9 Mbps on the upload, even though our older iPhone (on the Verizon network) doesn’t support all the latest DAS capabilities. Near the start of the game, as the pregame introductions were at their peak, we got a DAS mark of 18.0 Mbps / 15.7 Mbps in the middle of an upper-deck seating area (Section 227) and then a little bit after the game started, we got a mark of 21.3 Mbps / 12.5 Mbps near a bar area on the upper-level concourse.

Wi-Fi inside and out

On the Wi-Fi side of things, a visitor to Fiserv Forum can connect to the network even before coming in the doors, as part of the 623-AP Cisco installation includes Wi-Fi APs mounted on light poles in the “Deer District,” the plaza area on the stadium’s east side that connects to an outdoor beer garden and several bars and restaurants that were all part of the planned environment built in sync with the arena’s opening.

Before we went inside, we got a Wi-Fi speedtest of 40.5 Mbps / 40.2 Mbps in the middle of the Deer District plaza, which was hosting a pop-up haunted house attraction sponsored by Jack Daniels.

Inside the building, we again needed some guidance from the Bucks’ Cordova to locate some of the Wi-Fi APs, which are inside triangular enclosures that are either painted to match wall surfaces, or utilized as high-visibility section number signs, hiding the gear in plain sight.

Wi-Fi AP blended in to the wall covering

In the seating bowl, Fiserv Forum again shows its commitment to aesthetics with the smallest handrail enclosures we’ve ever seen, a discreet hand-sized enclosure that tucks the antenna components neatly into the top part of a railing, with the AP electronics hidden below the seating areas. Designed by integrator Johnson Controls and its ecosystem partners, Abaxent and AccelTex, the 28 special enclosures are also designed to be easy to detatch and re-attach (with something Johnson Controls calls a simple two-click “dart connector”) which facilitates keeping the network working when the lower-bowl seating areas need to be reconfigured for different events.

Sitting in a courtside seat near one of the handrail enclosures about 20 minutes before tipoff, we got a Wi-Fi speedtest mark of 15.8 Mbps / 33.2 Mbps. On the main concourse just after the game’s start we got a Wi-Fi mark of 28.6 Mbps / 60.4 Mbps, and later on at that same upper-concourse bar we got a mark of 39.9 Mbps / 61.1 Mbps.

Later on during the second quarter of the game, we watched another fan in our lower-bowl seating area spend most of the period keeping one eye on Monday Night Football streaming on his phone. “The Wi-Fi is really good here,” he noted.

Looking ahead to CBRS and 5G

As ExteNet and JMA prepare for the onslaught of the convention’s needs, in many areas the Bucks are already looking farther ahead, to future communications improvements including 5G millimeter wave deployments, and a possible introduction of CBRS services. Cordova, who is an advocate of the capabilities of private LTE networks over the CBRS spectrum, said the flexibility of provisioning services in a CBRS environment could be extremely useful for temporary needs, like during last year’s NBA playoffs when the NBA on TNT crew set up a temporary stage out in the plaza.

While the Bucks have already prepared for connectivity of all sorts out on the plaza space – from the top-level outside Panorama deck at Fiserv Forum that lets fans look out over the city, Cordova pointed out several metal boxes in the plaza that have home-run fiber connections for broadcast TV as well as remote power – there’s going to be all sorts of temporary connectivity needs when the convention media tents set up in the empty lot next door where the previous stadium, the Bradley Center, used to stand.

The fact that the Bucks and ExteNet were already well involved with planning for a July event in October the year before is just another sign of a networking operation that is well positioned now and already thinking about what the next necessary steps are.

Robert Cordova, chief technology and strategy officer for the Bucks, in the headend room

MatSing ball antennas point down from the rafters

The Daktronics centerhung video board

Superdome sees 10+ TB of Wi-Fi data at college playoff championship

The Mercedes-Benz Superdome. Credit all photos: Mercedes-Benz Superdome.

The upgraded Wi-Fi network in the Mercedes-Benz Superdome passed its first big test, with 10.12 terabytes of data used during the College Football Playoff National Championship between LSU and Clemson on Jan. 13.

With 76,885 spectators in attendance to witness LSU’s 42-25 victory in the championship game
(including President Trump, his entourage and accompanying security personnel), the
Superdome’s Wi-Fi performed beautifully. According to figures provided to Mobile Sports
Report by ASM Global (the entity that resulted from the September 2019 merger of Anschutz
Entertainment Group and venue management firm SMG), the Superdome’s wireless network
handled 41,475 unique users, along with 28,534 concurrent users. Fans generated 10.12 TB of
network data during the game, according to ASM Global contractor Dave Stewart. Top
applications creating that motherload of bytes (in order of usage) were iCloud, Facebook,
Snapchat and Instagram.

“The lower bowl and outer plaza area upgrades made a significant impact on patrons’ ability to
onboard to the system and flow into the building seamlessly. We saw a significant improvement
in the reduction of signal noise, resulting in cleaner, faster connectivity for individual devices,”
commented Matt Boyd, IT manager for the Mercedes-Benz Superdome and the adjacent
SmoothieKing Center and Champions Square facilities. “At the end of a long day, I was pleased
at the experience we were able to give our patrons, media, and the staffs of the various
organizations that make an event of this caliber happen.”

Newly installed APs outside in the plaza entry areas also kept things moving for fans and venue
management. “Paperless ticketing – a QR code on cell phone — accounted for over 85 percent
of the ticketed entry,” Stewart said. “We on-boarded over 40,000 unique devices at our entry
gates, which equates to over 60 percent of users accessing their ticket via Wi-Fi.”

Mercedes-Benz Superdome’s Wi-Fi upgrade ready for college championship game

The Mercedes-Benz Superdome, home of Monday’s college football playoff championship game, has had a recent upgrade to its Wi-Fi network. Credit all photos: Mercedes-Benz Superdome.

You didn’t have to strain to detect the air of renewal in New Orleans this past fall. By the river, in the French Quarter and surrounding neighborhoods there’s been construction cranes, scaffolding and fresh paint.

Drive by the skyline-dominating Superdome at night, and you’ll see a three-point star projected on its façade. Known as the Mercedes-Benz Superdome since 2011, it’s more visual evidence of how New Orleans has fought its way back since Katrina tried to drown the city in 2005.

Inside the Superdome, a technology renewal has been in progress this past football season. New Wi-Fi access points have been installed; the venue’s IT managers don’t just want to deliver more bandwidth – they want to manage it intelligently and wring maximum return from their investment. Which helps explain why they’ve embraced under-seat APs throughout most of the Superdome, shedding the previous back-to-front/blast ’em with bandwidth approach that sporting venues once widely embraced.

“We pay attention to what the NFL needs, what the New Orleans Saints require and what the fans expect,” said Dave Stewart, a contractor working with ASM Global, (the entity that resulted from the September 2019 merger of Anschutz Entertainment Group and venue management firm SMG). “That’s why we make incremental improvements and as needs change, we want to be responsive.”

Keeping up with devices and demand

And wireless technology has evolved since the previous system was installed in 2012. While the number of smartphone users coming to the Superdome seven years ago was relatively low, they’re now the norm, Stewart said. “Year over year, take rates have increased, as have expectations and utilization,” he added. With more users and higher bandwidth consumption, the back-to-front deployment model struggled to keep up; Stewart and his colleagues started looking at other AP solutions like handrail encasements, under-seat APs, or some kind of hybrid.

Under-seat AP enclosure

The Superdome now features under-seat APs on its terrace level, with custom enclosures supplied by Airwae and is moving to under-seat APs in its lower bowl. For concerts or spectacles like Wrestlemania that require seating on what might otherwise be the Saints’ 50-yard line, ASM sets up folding chairs on the floor, and zip-ties AP enclosures beneath them. Cable runs between the APs and the network ports are never longer than 50 feet, Stewart explained.

“Covering the floor is always difficult,” he added. “But deploying portable networks designed specifically for an event is something every multi-event venue must do.”

All told, the Superdome is up to 2,027 APs across the complex, which includes 410 newly installed APs in the lower bowl of the Superdome, all under seat. The upgrade is a sizeable increase from the previous 1,400 APs, which translates to approximately $7 million for the upgrade (Stewart wouldn’t divulge the exact amount). But he did say that physical infrastructure, cabling pathways and manpower account for 60 percent of a new install budget; 30 percent is typically hardware and licenses, and 10 percent goes to project management and design configuration.

Unlike most AP enclosures, those in the Superdome don’t rest on the ground; they’re bolted to the riser with about an inch of clearance at the bottom. Though most open-air venues power-wash their stands after an event, standing water doesn’t work inside the Superdome — moisture and its companions, rust and mold, are big issues. So Superdome officials procured an AP enclosure design that could be mopped under.

Keeping fans connected while they roam

Another aspect of the Superdome’s Wi-Fi installation is its focus on roaming, similar to the way cellular users get passed from antenna to antenna as they traverse an area. “We’ve designed Wi-Fi networks that onboard you, and the APs hand you off to the other APs,” Stewart explained. If users had to be re-associated with the Superdome’s Wi-Fi each time they activate their phone or move around the venue, that reduces airtime availability for them and the people around them, he added.

New APs were also added outside the stadium

Regular Wi-Fi tuning is also essential to ensure efficiency and quality; the Superdome uses use Cisco’s adaptive radio management (ARM) to help tune and optimize its Wi-Fi for crowd sizes, event types and different locations around the dome. “We assign different power ranges and different channels or available sets of channels to each access point or group of APs,” Stewart said.

The new APs have already spurred an uptick in connectivity and usage. Take rates are up to 70 percent with the under-seat APs according to Stewart. And about half of those users are actively uploading and downloading data, quadruple what he saw two or three years ago – and those numbers are climbing.

The Superdome is a Cisco shop; Stewart and his crew have been installing the vendor’s 4800 series APs and using the 802.11ac standard, also known as Wi-Fi 5. Next-generation APs, 802.11ax or Wi-Fi 6, are on Stewart’s radar and there’s a longer term transition strategy. While he sees Wi-Fi 6 as the future, he also knows the move will require a back-end upgrade, since legacy controllers don’t support an .ax solution.

“Since the pathway is such a high percentage of the cost, those AC enclosures will be re-useable,” Stewart said. The new enclosures are also designed to accommodate a larger cable size if needed.

Stewart likes the efficiencies that Wi-Fi 6’s OFDMA feature can wring out of the radio spectrum, coupled with its multi-user scheduling of the same frequencies, all of which will make a big impact on airtime performance. But Wi-Fi 6 benefits won’t truly be realized until most user devices support the standard. Right now only a small handful of devices (including the Apple iPhone 11 line) support Wi-Fi 6.

But Stewart and his team have a carrot to motivate them toward Wi-Fi 6 APs. A couple carrots, in fact: The NCAA Men’s Final Four in 2022, then Super Bowl 58 in 2024 (the fourth time the dome will host the NFL championship). They’re looking to ensure the best fan experience possible and that means plentiful bandwidth and seamless connectivity.

Stewart said it will take about 18 months to start the Wi-Fi 6 design and procurement process; they expect to start the project in 24 months and have it completed a year later, well in time for the Super Bowl.

“Part of our strategy is to have phased upgrades year by year to stay relevant and improve the customer experience,” Stewart explained. “Digital menus, better DAS, better Wi-Fi – we have to be attentive to what our fans want and deliver it year after year.”

New Report: Oklahoma leads the way with Wi-Fi 6

MOBILE SPORTS REPORT is pleased to announce the Winter 2019-20 issue of our STADIUM TECH REPORT series, the ONLY in-depth publication created specifically for the stadium technology professional and the stadium technology marketplace.

Our latest issue contains an in-person report on the new Wi-Fi 6 network installed at Gaylord Family-Oklahoma Memorial Stadium, and another in-person visit to see and test the new Wi-Fi network at Florida’s Ben Hill Griffin Stadium, aka “The Swamp.” This issue also has an in-person look at the wireless networks at Milwaukee’s Fiserv Forum and at Chase Center, the new San Francisco home of the Golden State Warriors.

You can READ THE REPORT LIVE right now in our new flip-page format, with no registration required! (Great for tablets and big phone reads!) You can also DOWNLOAD THE REPORT in PDF format as well!

We’d like to take a quick moment to thank our sponsors, which for this issue include Mobilitie, JMA Wireless, Corning, Boingo, MatSing, Cox Business/Hospitality Network, Oberon, and ExteNet Systems. Their generous sponsorship makes it possible for us to offer this content free of charge to our readers. We’d also like to welcome readers from the Inside Towers community, who may have found their way here via our ongoing partnership with the excellent publication Inside Towers. We’d also like to thank the SEAT community for your continued interest and support.

As always, we are here to hear what you have to say: Send me an email to kaps@mobilesportsreport.com and let us know what you think of our STADIUM TECH REPORT series.

Biggest NBA video board at Chase Center profiled in our latest VENUE DISPLAY REPORT!

Mobile Sports Report is pleased to announce the third issue of our new VENUE DISPLAY REPORT, with in-depth profiles of display technology at Chase Center, the new home of the NBA’s Golden State Warriors, and Fiserv Forum, new home of the NBA’s Milwaukee Bucks. No need to sign up or register — just click on the image below and start reading the issue today!

A new vertical-specific offering of MSR’s existing STADIUM TECH REPORT series, the VENUE DISPLAY REPORT series will focus on telling the stories of successful venue display technology deployments and the business opportunities these deployments enable. Like its sibling Stadium Tech Report series, the Venue Display Report series will offer valuable information about cutting-edge deployments that venue owners and operators can use to inform their own plans for advanced digital-display strategies.

Our reporting and analysis will be similar to that found in our popular STR series, with stadium and venue visits to see the display technology in action, and interviews and analysis with thought leaders to help readers better inform their upcoming technology purchasing decisions. And in case you are new to the MSR world, rest assured that all our VDR reports will be editorially objective, done in the old-school way of real reporting. We do not accept paid content and do not pick profiles based on any sponsorship or advertising arrangements.

Our third VDR issue takes an in-depth look at the display deployment at Chase Center, where the NBA’s largest main video board (from Samsung’s Prismview) leads the largest-ever deployment of LED pixels in and around any single venue. And at Milwaukee’s Fiserv Forum, learn how the striking Daktronics displays combine with the management power of Cisco’s Cisco Vision Dynamic Signage solution to give the Bucks a powerful platform for audience engagement and sponsor activation. Start reading the issue now! No registration needed!

As venues seek to improve fan engagement and increase sponsor activation, display technology offers powerful new ways to improve the in-stadium fan experience. While these topics are of prime interest to many of our long-term audience of stadium tech professionals, we suggest that you share the link with colleagues on the marketing and advertising sales side of the house, as they will likely find great interest in the ROI enabled by strategic display system deployments.

Sponsorship spots are currently available for future VDR series reports; please contact Paul at kaps at mobilesportsreport.com for media kit information.
