Closer Look: MatSing ball antenna deployment at Amalie Arena

Amalie Arena, home of the NHL’s Tampa Bay Lightning. Credit all photos: Paul Kapustka, MSR

Taking advantage of a cross-Florida drive, Mobile Sports Report finally got a live look at the MatSing ball antenna deployment at the Tampa Bay Lightning’s Amalie Arena, part of a new neutral-host DAS being built by AT&T. Some early returns on the MatSing ball network performance have gained a lot of attention, with rumors floating around this summer of multiple MatSing deployments either in the offing or already underway.

Since our visit was in the hockey offseason we didn’t get to test the DAS in action, but thanks to the hospitality of new Tampa IT director Andrew McIntyre (who recently left a similar position with the Chicago Cubs) we got to look around the arena at the MatSing deployment, which by AT&T’s count uses 52 of the distinctive round-ball antennas mounted in various places in the rafters.

We hope to return sometime this fall or winter to witness the network in action, but for now take a look at some of the peculiarities of the deployment, including the very specific angles for pointing the antennas toward very specific parts of the seating area.

What’s the buzz behind MatSings? Here is a bit of explanation from an earlier MSR story:

Why use MatSing antennas? What sets MatSing ball antennas (also called “Luneberg Lens” antennas) apart from other wireless gear is the MatSing ball’s ability to provide a signal that can stretch across greater distances while also being highly concentrated or focused. According to MatSing its antennas can reach client devices up to 240 feet away; for music festivals, that means a MatSing antenna could be placed at the rear or sides of large crowd areas to reach customer devices where it’s unpractical to locate permanent or other portable gear. By being able to focus its communications beams tightly, a MatSing ball antenna can concentrate its energy on serving a very precise swath of real estate, as opposed to regular antennas which typically offer much less precise ways of concentrating or focusing where antenna signals go.

What should bear watching in Tampa is the progression of the Water Street Tampa project, which includes Lightning owner Jeffrey Vinik and Microsoft’s Bill Gates as investors. Water Street, right outside the arena’s doors, is going to be yet another near-the-stadium downtown development area, though this one seems more ambitious than some of the stadium-centric plans around other new arena builds. We will of course keep track on how the wireless coverage goes from arena to outdoors. For now, enjoy some more close-ups of the MatSings:

Espo, or Phil Esposito, stands guard over the arena’s plaza

A look up from ice level. See how many MatSings you can count!
A little fuzzy, but you can see the different tilt angles here
MatSings and regular DAS antennas side by side
A look just outside the arena, where the Water Street Tampa development is underway

Little Caesars Arena revs the engine on wireless

Little Caesars Arena in Detroit is revving its engine with wireless deployments of Wi-Fi and DAS. Credit all photos: Terry Sweeney, MSR (click on any picture for a larger image)

Detroit has made an ambitious bet on the sports entertainment model with its 50-block District Detroit development – which embraces Ford Field (where the NFL’s Lions play), Comerica Park (MLB’s Tigers) and most recently, Little Caesars Arena (NBA’s Pistons and NHL’s Red Wings).

In fact, Motor City might just as easily be renamed Stadium City as Detroit looks to professional sports as one cornerstone of economic re-development.

The city has all four major pro sports teams competing within a few blocks of each other, noted John King, vice president of IT and innovation for Olympia Entertainment and the Detroit Red Wings. District Detroit plays host to more than 200 events, welcoming some 3 million visitors annually – not bad for an area that’s barely 18 months old.

Detroit’s hardly alone in riding this development wave. Sports entertainment districts are a proven engine to boost local economies and are popping up all over the country:
–Los Angeles’s LA Live complex uses the Staples Center as its hub but includes restaurants, hotels and plenty of retail;
–Houston Avenida gangs together Minute Maid Park, BBVA Compass Stadium and NRG Stadium, along with a convention center and hotels;
–Battery Atlanta houses the Atlanta Braves’ SunTrust Park and a Coca-Cola entertainment facility, along with retail, residences and hotels;
— Westgate Entertainment District in the greater Phoenix area houses State Farm Stadium (NFL’s Cardinals) and Gila River Arena (NHL’s Coyotes), plus the obligatory retail, restaurants and hotels.

San Francisco, Kansas City, Cincinnati and Sacramento and other cities are all building out similar sports entertainment developments in their downtown areas that encourage sports fans to make a night of it, or even a weekend. Even venerable venues like Green Bay’s Lambeau Field and Chicago’s Wrigley Field are also getting in the act of trying to build areas outside the parks to keep fans engaged (and spending) before and after events, or even when there’s no games being played.

Robust DAS, Wi-Fi in LCA

Editor’s note: This report is from our latest STADIUM TECH REPORT, an in-depth look at successful deployments of stadium technology. Included with this report is a profile of the new Wi-Fi and DAS networks being planned for the University of Colorado, as well as a profile of Wi-Fi at Vivint Smart Home Arena in Salt Lake City! DOWNLOAD YOUR FREE COPY now!

John King oversees the IT operations at Little Caesars Arena

King is pleased with the performance of the IT infrastructure at Little Caesars Arena since the $863 million venue opened in the fall of 2017. With a backbone of two 100-Gbps fiber connections, the arena counts more than 700 Cisco Wi-Fi access points. There are 364 APs in the bowl itself; the bulk of those – 300 APs – have been installed under seats to get the signals closer to where the users are.

Mobile Sports Report put LCA’s Wi-Fi network and DAS system to the test this season during a Red Wings home game against the New York Rangers. Due to personal technical constraints, we were only able to test Verizon’s portion of the DAS deployment; the Wi-Fi network tested was the District Detroit Xfinity SSID.

The good news is that both network types performed admirably. No surprise that bandwidth was most plentiful and speeds were fastest on concourses near concessions, as well as in the private clubs parceled around LCA. Fastest measured speeds: 139.68 Mbps download/33.24 Mbps on the DAS network outside the MotorCity Casino Club. The Wi-Fi was also well engineered there – 51.89 Mbps download and 72.34 Mbps upload were plenty fast for hockey’s power users.

We measured comparable speeds by the Rehmann Club with 134.4 Mbps/36.25 Mbps on the DAS, and 21.56 Mbps/120.8 Mbps on Wi-Fi. Similarly, connectivity was not an issue while standing in front of the impossible-to-miss Gordie Howe statue in LCA’s main concourse, where we clocked DAS at 102.95 Mbps/22 Mbps, and Wi-Fi at 43.34 Mbps/43.72 Mbps.

Speeds around the arena were generally in double-digit megabits, both for Wi-Fi and DAS. The Wi-Fi signal got a little sluggish in Section M7 (0.79 Mbps/3.03 Mbps) and Section M33 (1.68 Mbps/29 Mbps). Lowest measured throughput on the DAS network was in Suite 17 with 16.18 Mbps/17.41 Mbps, still plenty fast to handle most fan requirements.

Lighting Things Up in District Detroit

In tandem to LCA, there are approximately 1,000 APs also attached to the network that either handle District Detroit’s public Wi-Fi or connect to 34 parking lots and garages.

Wireless gear painted to blend in

“Our goal is to bring life and excitement throughout the District and not just focus on Little Caesars Arena,” King said. Video and digital signage are essential to that effort, both inside and outside LCA. The network enables more than 1,500 IPTV connections distributed across the arena, but also externally to LED boards and electronic parking signs. “We want to take the excitement from the event and run it out to the city – ‘5 minutes to puck drop’, on all those signs as one example,” King explained. “We can leverage [signage] for more than just the price of parking.”

The network uses the Cisco Vision IPTV digital display management system to control display programming, including advertising that appears on video screens in LCA’s many hospitality suites. With five TV screens per suite, LCA deploys an L-shaped “wrapper” around the main video image used for advertising. “We rotate that content in the suites and run loops in concourse before and after events,” King said. “It allows us to put scripting in different zones or post menus and dynamically update prices and items for sale.” LCA’s concessionaires can change the price or location of food and beverage items, all through the networked point-of-sale system.

Tune-able Wi-Fi

The District Detroit app is divided into three “buckets,” according to King: Detroit Red Wings, Detroit Pistons and 313 Presents — all the events and entertainment outside of sporting events (313 is Detroit’s area code). When configured for hockey, LCA can accommodate up to 19,515 Red Wings fans; as a basketball arena for the Pistons, LCA holds 20,491. But some events may draw fewer people and King and his team adjust accordingly.

“We’re an arena for 20,000 fans and as we looked at that density, we found that 10,000 fans behave differently and we’ve had to tune the arena differently based on traffic flows,” he said. When completely full, Wi-Fi signals must pass through so many “bags of water,” as RF engineers sometimes describe human spectators. Half as many fans means that Wi-Fi signals behave differently, consequently, a fan may connect to an AP that’s less than ideal, which can affect both user experience and system performance.

An under-seat Wi-Fi enclosure

“We’ve looked at some power tweaks and tuning; we also have the ability to tune [the arena] on the fly,” King said, but emphasized that the venue’s Wi-Fi doesn’t get re-tuned for every event. “We try to find the sweet spot and not do that too much. On an event day, we try not to touch anything that isn’t broken,” he said.

Previews of coming attractions

Like any sports and entertainment IT exec, King is looking at ways to improve the fan experience and derive more performance and revenue from Olympia’s IT investment. Buoyed by the success of mobile ticketing at LCA, King said he’d like to find some way to use biometrics to help speed up transactions at counters and pedestals throughout the arena. And he’s excited about 5G cellular deployment, which he believes could compete with Wi-Fi if 5G delivers on all that’s been promised by carriers.

LCA’s app uses Bluetooth for navigation, letting fans input their seat information for directions. “Right now, we have pre-order pickup, but in-seat service is something we’re looking at. What other line-busting technologies can we do?” King said.

And while fans can pre-order food and beverages at LCA, King also wonders if pre-ordering of team merchandise (“merch”) is something that would appeal to fans and be easy to execute. “We’re looking at a Cincinnati venue where they have compartments for food, hot or cold, that’s been pre-ordered,” he said, wondering if a similar compartmentalized pickup system be used for merch.

King sees plenty of room for improvement in overall management reporting across IT systems at LCA and the 12,000 active ports that keep systems humming.

“Everything is connected and our electricians can use their iPads to dim or turn on lights anywhere in the building,” he said, adding that everything’s monitored — every switch, every port. “It would be nice to see more information around traffic flow and performance patterns. We’re seeing a little bit of that. But I’d like to see network information on people tracking and doors, and correlate visual information with management data.”

Another set of metrics King can’t get at the moment: Performance data from AT&T, T-Mobile and Verizon about LCA’s 8-zone DAS system. King said he’s talking with Verizon, the lead DAS operator at the venue, about getting autonomous reports in the future, but for the time being King and his team don’t have much visibility there. The DAS uses the Corning ONE system.

Amalie Arena’s MatSing-powered DAS ready for Women’s Final Four

MatSing ball antennas seen behind championship banners at Amalie Arena. Credit all photos: MatSing (click on any photo for a larger image)

The new DAS at Amalie Arena in Tampa, which uses 52 MatSing ball antennas, is fully operational and ready for this weekend’s NCAA Women’s Final Four, which starts on Friday.

According to AT&T, which is running and operating the new DAS, the new network “is officially on-air,” after going through some test runs during Tampa Bay Lightning NHL games. According to one informer, AT&T CEO John Donovan (an old friend of MSR) attended a recent hockey game at Amalie and gave a big thumbs-up to the new DAS, which is the biggest known installation of the unique MatSing antennas, which are basically huge spheres with lots of directional cellular antennas inside.

A press release from AT&T about the new DAS claims that has boosted cellular capacity inside Amalie Arena by 400 percent from last year. The new DAS also uses Corning ONE gear on the back end.

MSR will be in Minneapolis this weekend at the other Final Four, so if you are in Tampa for the women’s tourney take a speedtest or two on cellular and let us know what you see. We are watching the DAS deployment at Amalie Arena carefully since it is our guess that it won’t be the last you hear of MatSing deployments this year. Some more photos from the Amalie Arena MatSing deployment below.

Venue Display Report: Sharks bring ‘excitement’ to SAP Center concourses with new digital display technology from Daktronics and Cisco

A long LED board lights up the main concourse at the San Jose Sharks’ home, SAP Center. Credit all photos: Paul Kapustka, MSR (click on any picture for a larger image)

If you’re an ice hockey fan, you are no doubt somewhat addicted to the excitement of seeing games live, in person. Yet one historical drawback to going to games has always been fearing those moments when you need or want to leave your seat, when missing out on the unpredictable action makes waiting in lines excruciating.

While many teams in all kinds of sports have been busy installing television screens in concourses and concession areas to help keep fans connected to the live action, at SAP Center in San Jose the NHL’s Sharks have taken concourse display technology to a new level: With cutting-edge LED displays from Daktronics and the Cisco Vision IPTV display management system from Cisco, the Sharks have turned what used to be basically a dark concrete tunnel into a well-lit, display-laden walkway that can bring live game action and exciting, engaging marketing messages to fans while they are outside the bowl, keeping the excitement level high no matter where in the building a fan might be.

The most visible part of the new display deployment, one installed in phases over the last two seasons, are the concourse LED boards from Daktronics, displays that were custom designed for the stadium’s walkways. Robin Hall, a regional manager for the Brookings, S.D.-based Daktronics, said there were a total of 17 displays added to the main concourse at SAP Center, all 3 1/2-feet tall but in many different widths, with one measuring almost 66 feet wide.

Narrow Pixel Pitch LEDs make a difference

Editor’s note: This profile is from our new VENUE DISPLAY REPORT series, a vertical-specific offering of MSR’s existing STADIUM TECH REPORT series. The VENUE DISPLAY REPORT series will focus on telling the stories of successful venue display technology deployments and the business opportunities these deployments enable. No registration or email address required — just click on this link and start reading!

John Castro, vice president of corporate partnerships for the Sharks, said the concourse displays are just the latest step in an ongoing process to “keep the venue updated and modernized.” Now celebrating its 25th year in existence, SAP Center recently hosted the NHL’s All-Star Game and is a regular stop for such big-ticket events as NCAA basketball regionals and U.S. Figure Skating championships.

In 2010, Castro said the arena added a new Daktronics center-hung video board, which has distinctive circular ribbon boards above and below that synchronize with the ribbon board that circles the arena in the middle of the seating areas. A few years ago, the arena put out an RFP to bring Wi-Fi to the stadium, and when it picked Cisco for the gear supplier, it also decided to use Cisco Vision to synchronize a new display strategy for the building’s main concourse.

“The idea was, let’s emulate what people see in the seats and bring it to the concourse,” Castro said.

A new LED screen above an entryway

What was eventually installed over the past two seasons were the new wall-mounted displays, which joined the 240 TV screens and the 16 hanging pendant displays (with six screens each) that were already in the concourses. According to Castro the Sharks took down eight static signs to make room for the new, interactive displays.

All the new displays make use of Daktronic’s new Narrow Pixel Pitch (NPP) technology, which feature 2.5-millimeter line spacing. The close alignment of the LED lights in the displays makes them sharp even from close distances, with a look and feel more like a traditional TV screen than an LED ribbon board.

By using LED technology, not only are the boards more flexible in what kind of content they can carry, but they are also cheaper and more resilient than TV screens, something Hall said matters a lot to venues like SAP Center that may see up to 300 live events a year.

“If you have TVs, you have to replace them often, and over a lot of hours [the expense] is hard to justify,” said Hall. With its LED technology, Daktronics was able to create custom size boards to fit different areas in the concourse (like above the entry and exit doorways, or above the main entry openings to the seating bowl), giving the Sharks lots of flexibility to build their new concourse viewing experience.

Bringing Cisco Vision to control displays

To make fans take notice of the new displays, the Sharks turned to Cisco and its Cisco Vision IPTV display management system, which allows teams and venues to program and run multiple displays from a single management system. Cisco also brings to the table years of experience in designing, deploying and selling display systems and system content, which can help teams like the Sharks not only keep fans more engaged but also help the team improve its digital ad sales.

Cisco, which supplied the Wi-Fi gear when SAP Center got its new wireless networks a couple years ago, teamed up with network deployment partner AmpThink to deploy a new display system at the same time, often doubling up on infrastructure. At many points inside the arena, a display screen is mounted in the same space as a Wi-Fi access point, an efficient design that combines aesthetics (the APs are hidden behind the screens) with cost savings.

Menu screens and live action are side-by-side to keep fans engaged

According to Ken Martin, executive director of digital transformation for the consumer industries in the Americas and for the sports and entertainment industry globally at Cisco, the Sharks’ previous display system was limited in its capabilities, especially in the ability to change things like menu boards easily between events. Martin also said the Sharks had four different signage solutions for the various boards and displays throughout the stadium, making it hard to coordinate programming across screens.

Now with Cisco Vision in place, the Sharks can build “shows” of content and advertising that flow from screen to screen, or arrive simultaneously on multiple screens to increase the visual effect. Inside the SAP Center concourses, the new Daktronics panels combine with an previously existing infrastructure of screen displays hanging over the walkways to create a visual “wall” that draws the eye.

“The way [the screens] are positioned, you cannot stand in the SAP Center concourses without being hit by something,” Cisco’s Martin said.

The Sharks’ Castro said there “was a lot of discussion and research” about the placement of the signs.

“Whether you turn left or right, you’re always going to see an LED,” Castro said.

How to use digital displays to entertain and inform

Through its professional services that are part of the Cisco Vision deal, Cisco also helps the Sharks brainstorm with potential sponsors to create digital display advertising ideas, and then also helps create, produce and run the “show” of ads that streams across all the stadium’s displays. A current campaign with BMW is an example of using all concourse screens simultaneously to create an immersive feel to the advertising.

A look at the hanging pendant screens in sync with the LED wall boards

“Part of what we do is show customers the art of the possible,” said Martin, who said many demonstrations of digital-display potential can happen in his team’s extensive demo room at Cisco, where they have 27 different types of screens to model just about any possible stadium deployment. Though much of the digital advertising industry in venues is still in an adolescent stage, Martin said that sponsors are “way more educated than they have ever been,” and know now that they can ask for particulars like having ads shown at certain times, or to have advertising content “wrapped” around live action on partial screen real estate, like an “L-wrap.”

With Cisco Vision, the Sharks are able to not just coordinate a “show” of ads and other content during the game, but they can also break in and trigger special screen content when something happens live, like a goal being scored. Such “takeover” moments are just another new asset that can be added to the ROI for a smart digital display solution, something not possible with static display systems. Such timely messages can really catch the fans’ eye, especially so at hockey games where people pay attention when they aren’t in their seats.

“If you’re a true hockey fan, you have your concourse timing down to a science,” said Daktronic’s Hall. “You never want to go to the game and feel like you’re missing something.”

To help those fans, one of the live action content pieces run across most of the concourse boards at SAP Center is a live clock that counts down the time until live action starts again.

“It can really be a showstopper, to use the screens and video walls, especially when they are all synchronized to the same message,” Cisco’s Martin said. “You’re going to get people to stop and pay attention.”

For the Sharks, the new system is already returning dividends; according to Castro, some 80 percent of all new digital display sponsorship business includes Cisco Vision integration as part of the opportunity.

“It helps [ads] rise above the clutter,” Castro said of the new display system. “You can see the impact on the brands as well as on the fans.”

“It’s like putting on a show in the concourse,” Daktronic’s Hall said of the new system. “It really extends the in-bowl experience through the whole venue.”

Editor’s note: This profile is from our new VENUE DISPLAY REPORT series, a vertical-specific offering of MSR’s existing STADIUM TECH REPORT series. The VENUE DISPLAY REPORT series will focus on telling the stories of successful venue display technology deployments and the business opportunities these deployments enable. No registration or email address required — just click on this link and start reading!

Notre Dame Stadium sees 4 TB of Wi-Fi used at NHL Winter Classic

It wasn’t a record-setting day for the Wi-Fi network at Notre Dame Stadium, but the 4 terabytes of data used by fans at Tuesday’s NHL Winter Classic continued a string of healthy wireless data use by attendees at the recently renovated venue.

With 76,126 in attendance to watch the Boston Bruins beat the Chicago Blackhawks in the latest of the NHL’s outdoor-arena games, some 17,000 unique devices connected to the stadium’s Wi-Fi network, according to statistics provided by the university. The peak concurrent Wi-Fi connections were 14,355, and peak throughput was 5.81 Gbps, according to the school. Given the winter weather and the fact that many fans were no doubt visiting Notre Dame for the first time, it’s no surprise that the data usage trailed all the other events at Notre Dame Stadium this fall and winter (see chart below). Still, a 4 TB day is still a big number, and again perhaps more impressive considering the conditions. Earlier this fall, Notre Dame Stadium saw 7.19 TB used for a game against Stanford.

According to some reports, including this story from CBS News, the second-largest ever Winter Classic crowd saw some issues arise on the concessions side, with some fans reporting that the stadium had run out of food and beer and that many concession lines were extremely long. Another report quoted a Notre Dame spokesperson as saying the reports of being out of food or beer were untrue.

More Wi-Fi stats from Notre Dame’s fall and winter events below. Thanks again to Notre Dame’s IT crew for providing the figures.

Philadelphia Flyers pick Venuetize for new stadium app

Screen shot of Venuetize’s new app for the Philadelphia Flyers and Wells Fargo Center.

The NHL’s Philadelphia Flyers have tapped app builder Venuetize for the team’s new stadium app for Wells Fargo Center, an app that includes digital ticketing support for now with other features planned for a later arrival.

According to a press release from the Flyers and Venuetize, the new app will allow fans to completely manage, transfer and scan tickets for all events at Wells Fargo Center, eliminating the need to print paper tickets at home. While the release did not specify which additional features would be available soon, screen shots of the app showed support for digital parking tickets and the ability to order concessions through the device.

The win with the Flyers is the second NHL deal for Venuetize this year, following being picked to develop the Tampa Bay Lightning’s new app earlier this year. Venuetize also counts the Detroit Red Wings and the Buffalo Sabres among its team-app clients.
