Minnesota United MLS home opener at Allianz Field sees 85 GB of Wi-Fi

One of the Cisco Wi-Fi APs installed by Atomic Data inside the new Allianz Field in Minneapolis. Credit: Paul Kapustka, MSR (click on any picture for a larger image)

A chilly home opener for the Minnesota United soccer team in their brand-new Allianz Field saw 85 gigabytes of data used on the stadium’s Wi-Fi network, according to statistics provided by Atomic Data, the stadium’s technology provider.

With 19,796 fans on hand on April 13 to pack the $250 million venue, Atomic Data said it saw 6,968 unique Wi-Fi device connections, a 35 percent take rate. The Allianz Field Wi-Fi network uses Cisco gear with 480 Wi-Fi APs installed throughout the venue. Approximately 250 of those are located in the seating bowl, with many installed under-seat. The stadium also has a neutral-host DAS built by Mobilitie, though none of the wireless carriers are currently online yet. (Look for an in-depth profile of the Allianz Field network in our upcoming Summer STADIUM TECH REPORT issue!)

According to the Atomic Data figures, the stadium’s Wi-Fi network saw peak Wi-Fi bandwidth usage of 1.9 Gbps; of the 85 GB Wi-Fi data total, download traffic was 38.7 GB and upload traffic was 46.3 GB. Enjoy some photos from the opening game (courtesy of MNUFC) and a couple from our pre-opening stadium tour!

The game was opened with a helicopter fly-by


A look at the standing-area supporter end zone topped by the big Daktronics display

The traditional soccer scarves were handy for the 40-degree temperatures

A view toward the field through the brew house window

The main pitch gets its opening salute

Entry ways were well covered with Wi-Fi to power the all-digital ticketing

The Loons have a roost!

The view as you approach the stadium crossing I-94

One of the under-seat Wi-Fi AP deployments

Message boards let fans know how to connect

Chargers, Mobilitie pump up the DAS at StubHub Center

While the new LA stadium is being built, the soccer-specific StubHub Center is the home to the NFL’s Los Angeles Chargers. Credit all photos: Terry Sweeney, MSR (click on any picture for a larger image)

Mention StubHub Center to your average sports fan in southern California and they’ll likely assume you’re talking about soccer’s LA Galaxy or the Los Angeles Chargers, the recently relocated NFL franchise subletting space while its permanent stadium gets built.

But StubHub Center, built on the campus of California State University/Dominguez Hills, also includes a velodrome, an 8,000-seat tennis stadium (with several adjacent courts), and an outdoor track and field facility. Throw in the far-flung parking lots and it adds up to 125 acres that all need wireless connectivity.

With such wide spaces to cover, StubHub management opted not to spend on fan-facing Wi-Fi and instead focused on distributed antenna system (DAS) technology to keep fans and tailgaters connected. Katie Pandolfo, StubHub’s general manager, looked to the major cellular carriers to invest in and support the connectivity needs of Galaxy and Chargers fans, and other eventgoers at the open-air StubHub.

Carriers help bear the cost of connectivity

Editor’s note: This profile is from our latest STADIUM TECH REPORT, an in-depth look at successful deployments of stadium technology. Included with this report is a profile of Wi-Fi at Nebraska’s Memorial Stadium, a sneak peek at Milwaukee’s new Fiserv Forum, and a profile of the new Wi-Fi network being added to Wrigley Field! DOWNLOAD YOUR FREE COPY now!

Katie Pandolfo, StubHub’s general manager

“With our DAS-only approach, the investment is 100 percent on the carriers and doesn’t cost us anything,” Pandolfo told Mobile Sports Report. While they got a few complaints about no public Wi-Fi during events in 2017, when the 29-zone DAS system was activated, fans quickly acclimated and now use bandwidth from Sprint, T-Mobile and Verizon on the shared network. AT&T isn’t part of the DAS system, but has operated a macro site at StubHub for years, according to Pandolfo.

Mobilitie helped build StubHub’s DAS system and offered its engineering expertise; the turnkey provider also manages the system. The DAS-only approach is common in southern California; in addition to the Rose Bowl in Pasadena, the Honda Center in Anaheim and Viejas Arena (under construction) at San Diego State University are also DAS-only venues with no fan-facing Wi-Fi.

StubHub Center, located in Carson, Calif., is 17 miles south of downtown Los Angeles, and upwind from a nearby Goodyear blimp mooring station; gusty coastal winds apparently make this a good training ground for new blimp pilots. The 27,000-seat StubHub originally opened in 2003 as Home Depot Center; the new sponsor came onboard in 2013. Anschutz Entertainment Group owns and operates StubHub Center.

StubHub will handle several events when Los Angeles hosts the Summer Olympics in 2028, including bicycle track racing, field hockey, pentathlon, rugby and tennis. Pandolfo expects firmer plans for the venue’s technology needs to emerge sometime in the next couple years. Technology – especially wireless technology – will change a lot in that time, she noted.

As the second soccer-specific stadium built in the U.S., Major League Soccer’s LA Galaxy is the venue’s premier tenant. But in 2017 when the National Football League’s Chargers moved from San Diego to Los Angeles, the facility underwent some major upgrades. Additions include 1,000 new tip-up seats replacing bleachers on the east side of the stadium; another 330 bleacher seats were added in StubHub’s southeast corner. Luxury suites and the press box were renovated along with two new radio booths; they also added a security office for police and NFL officials, and camera booths at the two 20-yard lines and at the 50-yard line. Locker rooms were enlarged as was the press conference room.

DAS antennas look down from atop a wall

And tempting as it may be to lump all fans of any sport into a single heap, Pandolfo said Galaxy fans and Chargers fans behave very differently at StubHub Center. Chargers fans like to get up and walk around, visit concessions and take advantage of the venue’s amenities during the game. Not so for Galaxy fans, who tend to stay seated and don’t want to miss any of the action, she explained.

California’s Department of Alcoholic Beverage Control also just changed its rules and will now allow beer sales up and down the aisles of stadiums like StubHub Center. Beer hawking, she noted, didn’t used to be digital and required fans to pay cash. “Now it’s a quicker transaction that improves the fan experience,” using mobile pay systems or credit cards, Pandolfo said.

DAS upgrades mean faster speeds

In the meantime, Mobilitie continues to optimize StubHub’s DAS system; based on bandwidth speed tests conducted by Mobile Sports Report, things are moving in the right direction. MSR tested Verizon DAS connectivity right after the system was installed in August 2017, and a year later during a Chargers’ pre-season game against New Orleans. In 2017, Verizon’s DAS struggled in single-digit Mbps uploads and downloads; quite often, the throughput was even less.

What a difference a year makes. Mobilitie engineers’ fine-tuning has paid off; August 2018 tests show dramatic improvement, with the highest throughputs near the stadium’s northwest concessions area — 111.39 Mbps/12.15 Mbps (download/upload). A year previous, things were a lot more sluggish with 0.95 Mbps/0.04 Mbps speeds recorded in the same area.

Overhangs provide good places for equipment mounts

DAS performance has also improved just inside the gates past the ticket scanners at the bottom of the stairs; in 2017, we clocked only 1.87 Mbps/13.42 Mbps, but more recently throughput had jumped to 87.08 Mbps/21.42 Mbps. The concession area on the east side of the stadium checked in most recently at 76.55 Mbps/6.7 Mbps, another sizeable increase from last year when Verizon DAS throughput was a pokey 0.4 Mbps/0.06 Mbps.

Speeds inside the stadium have also improved year-over-year. Section 230 in the northeast corner of StubHub measured 2.83 Mbps/1.96 Mbps a year ago, but were up to 13.48 Mbps/8.71 Mbps in August 2018. Similarly, the sunny northern end of the stadium above the end zone delivered 0.21 Mbps/0.27 Mbps a year ago, but jumped to a more acceptable 16.44 Mbps/18.27 Mbps. The east side of the stadium is also more robust; a year ago, bandwidth tests yielded 3.1 Mbps/0.01 Mbps, but were up to 8.97 Mbps/1.74 Mbps.

Improvements to the DAS network performance can only help improve the fan experience at StubHub Center. Pandolfo wants fans to be able to do everything faster: Get parked faster, enter the stadium, and take advantage of all the food, drink and merchandise options. “We look at the whole package and then at the network we have to provide to make that happen,” she said. “We’re looking at it from the fan experience but also how to optimize revenue for the building.” It’s the right formula for sporting venues compelled to balance technology requirements against dollars and cents.

Successful opener for LAFC at Banc of California Stadium in Los Angeles

Banc of California Stadium looks over downtown Los Angeles on its opening game day. Credit all photos: Terry Sweeney, MSR (click on any photo for a larger image)

First you heard the booming bass of drums, then came the chanting of thousands (“FC!…LA!…FC!”). You may not see the Banc of California Stadium at first, but this aural GPS guides fans toward Major League Soccer’s newest venue, which opened April 29 with expansion team Los Angeles Football Club. With a final price tag of $350 million (~$100 million over its original budget), the stadium is the most expensive for a soccer-specific venue.

First things first: The Ruckus-based Wi-Fi and its 500 access points functioned beautifully, as did the DAS network that Mobilitie helped engineer – more on that in our upcoming summer STADIUM TECH REPORT issue next month.

The freshly minted wireless infrastructure ensured attendees on opening day could Instagram the U.S. Navy paratroopers landing center field, trailing colored smoke out of their heels (black and yellow/gold, LAFC’s colors, of course). Or the surprise appearance of comedian Will Ferrell (who also owns part of LAFC), balancing a hooded bird of prey on his wrist. Olly, LAFC’s mascot, then hopped to the arm of its usual handler who released the falcon, thrilling the crowd with its gliding and swooping, completely unfazed by 22,000 fans and their cheers.

But for sheer endurance, raucous fans in the north stands put on the biggest show, beating drums, waving flags (Brazil, Argentina, Portugal, to name a few), and singing fight songs. The drummers kept things lively throughout the game, even if they were occasionally obscured by the yellow/gold smoke bombs set off at strategic moments.

A blazing open to the LAFC’s new home.

At regular intervals throughout the inaugural game against the Seattle Sounders, the feeling was less southern California and more like one of South America’s soccer stadiums.

The stadium is well named, if only because it has the sound and spirit of a giant cash register. Multiple establishments – Founders Club, Sunset Deck, Field Level Club, Figueroa Club, Directors Lounge – ensure no one goes hungry or thirsty. Luxury suites fill in the gaps. Down on the main level, LA’s tastiest eateries (tacos, barbecue, Korean, shawarma, coffee, craft beers) have outlets and the lines were long on opening day. There are also the obligatory team merchandise and souvenir stands and season ticket vendors.

Making money is one goal for LAFC, but so is winning games. LAFC triumphed in its debut home game 1-0, thanks to a free kick by team captain Laurent Ciman. That’s an auspicious start for MLS’s newest franchise and its shiny newest stadium.

Video boards are big at Banc of California Stadium

Steep seating pitches and sun screens make this stadium fan-friendly

The entry to the newest stadium in the MLS

Cranes, dust dominate Los Angeles venue sites

Three Los Angeles-areas venues are under construction for soccer, football and the 2028 Summer Olympics.

Workers install turf at the Banc of California Stadium (click on any photo for a larger image)

Between the cranes, earthmovers and swarms of fluorescent vests, you’d be forgiven for mistaking the Los Angeles basin for a construction zone. Sporting-wise, there are three construction zones, including a new stadium for a Major League Soccer latest expansion franchise, the venerable Coliseum gets a much needed renovation, and a bling-y NFL stadium starts to emerge from the silt of the Angeles alluvial plain.

Construction or renovation plans for all the venues were underway before the International Olympic Committee awarded the 2028 Summer Games to Los Angeles last fall; all three venues are expected to host Olympic events in a decade.

Banc of California Stadium opening this April

Editor’s note: This profile is an excerpt from our latest STADIUM TECH REPORT issue for Spring 2018, which includes a look at Wi-Fi performance during the Final Four, a recap of wireless performance at Super Bowl 52, a profile of the Vegas Golden Knights’ T-Mobile Arena and more! DOWNLOAD YOUR FREE COPY right now from our site!

Let’s take them in the order they’re expected to open. In its inaugural season, Major League Soccer’s newest franchise, Los Angeles Football Club, is moving with speed and efficiency to make sure the Banc of California Stadium is ready for LAFC’s first home game April 29.

The 22,000-seat venue features steep stands (35-degree angles), with no seat more than 135 feet from the playing field. IBM was tapped to handle the stadium’s technology requirements in October 2016; Ruckus supplied the access points for the new stadium, according to Christian Lau, LAFC’s VP of information technology. About 500 APs will blanket the stadium with Wi-Fi; Lau told Mobile Sports Report that number could “possibly trend higher.”

Construction at the LA Coliseum

Right next door (literally) is the Los Angeles Coliseum, where demolition began in January after the NFL’s Los Angeles Rams playoff loss to Atlanta. Located on the campus of the University of Southern California, the Coliseum is home field for both the Rams (at least til 2020… more on that in a second), and the USC Trojan football team. The Coliseum has already hosted opening ceremonies for two Olympiads and is poised to do the honors again.

Coliseum upgrade means fewer seats, more Wi-Fi

In the meantime, construction crews are working 16 hours a day, six days a week, according to Derek Thatcher, IT manager at the Coliseum and an employee of USC, which oversees and administers the venue for Los Angeles County. This is the eighth renovation of the 97-year old venue; in addition to making the bowl ADA-compliant, this latest upgrade will add more aisles and larger seats, reducing capacity from 93,607 to 77,500.

New Wi-Fi is also part of the renovation plan; no word yet on which vendor will supply gear, though Mobilitie donated Aruba APs last year for use in the student section and elsewhere in the bowl.

About half the Coliseum’s $270 million renovation will be done during this year’s football offseason; a new field and refurbished seats will be ready for the Rams and Trojans by late summer. Remaining construction and upgrades will be completed in the 2019 offseason, according to Coliseum officials.

Meanwhile, 9 miles southwest of USC in the LA suburb of Inglewood, the arcs of a bowl for the Los Angeles Sports and Entertainment District at Hollywood Park
are taking shape. Construction crews broke ground in late 2016 to transform a 300-acre site into a gleaming new sporting destination. The $2.6 billion complex will be shared by the Rams and the Los Angeles Chargers starting in 2020; LA Stadium is scheduled host the Super Bowl in February 2022.

With a capacity of 70,000 (expandable to 100,000), the stadium’s indoor/outdoor design and a two-sided, 120-yard oculus video display are already generating buzz. Site managers haven’t mentioned any network technology or which vendors they’re considering for wireless and other IT requirements. LA’s Olympic planning committee also reserved the option to use the stadium and the Coliseum for dual-venue opening and closing ceremonies in 2028. Using the Coliseum satisfies the Olympic purists; mixing in LA Stadium would provide the glitzy spectacle global audiences have come to expect from Olympics hosts.

Orlando City Stadium adds high-density Wi-Fi for soccer fans

Orlando City Stadium, home of the MLS’s Orlando City SC. Credit all photos: Jenna Cornell (click on any picture for a larger image)

Resilient. Connected. Reliable. Even before its new stadium opened in March of this year, Orlando City SC, the Major League Soccer franchise in central Florida, knew exactly what it wanted from fan-facing Wi-Fi.

Leading that list was networking infrastructure to support the stadium’s 25,500 capacity. The team needed to be able to deliver live streaming video to fans through the team’s LionNation app. And they wanted a way to begin collecting user info and building relationships with fans, according to Renato Reis, CIO for the club.

And with so many professional sports teams having already installed wireless infrastructure, Reis knew there was no reason to reinvent the Wi-Fi wheel. “I had the privilege to travel and interview other organizations,” he said, including the Hard Rock Stadium in Miami where the NFL’s Dolphins and the University of Miami both play football, as well as MetLife Stadium in East Rutherford, N.J., shared by the NFL’s Jets and Giants. Reis said Orlando City SC’s technology drew heavily on the experience and deployment of Levi’s Stadium in Santa Clara, Calif. “I used what I learned,” he laughed.

Paying their own way

Orlando City is barely 3 years old and played its first two seasons in the nearby Citrus Bowl, now called Camping World Stadium.

Under-seat Wi-Fi deployment at Orlando City Stadium.

After some confusion with the City of Orlando, Orange County and the state of Florida over money and budget for a new stadium, Orlando City SC’s ownership abandoned a public-private partnership to go its own way. Orlando City Stadium was built with private funds and opened in time for this year’s opener. Orlando City SC shares the venue with the Orlando Pride, the women’s professional soccer team.

“We had a brand-new stadium and no installed Wi-Fi, two factors that really benefited us,” Reis told Mobile Sports Report. “We planned the position of our antennas and leveraged lessons from other organizations to design something from scratch and build for the future.”

Orlando City SC had some help there. The MLS franchise partnered with managed service provider Spectrum Enterprise, a division of Charter Communications; Spectrum in turn has a longstanding partnership with Orlando City’s equipment vendor, Cisco. Together, they installed networking gear, lots of new fiber-optic cable, and the wireless infrastructure that rides atop the stadium’s 10-Gbps backbone network.

The fan-facing Wi-Fi consists of more than 550 wireless access points around the stadium, or about one AP for every 45 users. The APs are installed under seats, in handrails and on posts. “It was more of a challenge to find the right places, design-wise, for APs to keep them out of people’s line of vision,” Reis said.

Orlando City CIO Renato Reis, posing in front of some cool graffiti and below a Cisco AP.

Supporting streaming video

AP density and processing power were important considerations for Orlando City SC. With such dense coverage, each AP delivers 50-80 Mbps per user, Reis said. That ensures that users of the team’s LionNation app enjoy high performance when using its streaming video capability; users posting to social media or checking email also get faster throughput, he added.

That sort of performance is essential, especially for users of the premium version ($8.99) of the LionNation app. In addition to live-streaming video, premium members get access to behind-the-scenes content, as well as 10 percent discounts off food, drink and merchandise purchases (and points for every dollar spent). They also get priority access to post-season tickets and single-game tickets.

Spectrum helped with the stadium’s engineering and remains active in day-to-day management, said Reis. Spectrum performed three rounds of Wi-Fi tuning and collecting data to see where usage was greatest. No surprise: Entry gates and concession areas, according to Reis. They then made adjustments, repointing APs where needed, thus ensuring bandwidth is available where it’s needed most.

Orlando City SC has also been testing wireless food ordering in one stadium section with 1,500 users since the beginning of the year. “The challenge there isn’t technology but rather logistics,” Reis explained.

Screenshot of the Orlando City app

The team is planning to extend the capability more broadly, but needs more experience to help decide how to proceed. “We’ll probably run the test for the rest of the season and make changes next year,” he said.

Reis’s biggest challenge for the moment is encouraging Wi-Fi usage – and also persuading users to register if they’re not on the app. Even with Orlando City Stadium’s Wi-Fi coverage, most users will stick to cellular (the stadium’s DAS network is serviced by AT&T, Verizon T-Mobile and Sprint), he said.

“The problem I’m trying to solve is who is at the stadium,” Reis explained, adding that the only information he has is that a fan bought four tickets, for example, and when they get scanned at the gates. So how to learn more? “Most landing pages are boring,” he laughed; still, he’s considering offering different incentives for Wi-Fi users to check in.

“Can I loyal-ize you so I can learn what you like, what offers are more appealing, what you enjoy and don’t?” Reis asked. That’s a primary challenge for most sports teams, entertainment companies and ecommerce entities. Luckily for Reis and the Orlando City SC, he’s got the bandwidth, backbone and people resources to learn more about fans and build those relationships going forward.

Red Bull Arena grabs Wi-Fi by the horns

The New York Redbulls take on NYCFC at Red Bull Arena on Sunday night May 9, 2015 in Harrison, NJ.
Ben Solomon/NYRB

The New York Red Bulls have proven themselves very goal-oriented on the soccer pitch, so it was no surprise the team was equally methodical when they began a Wi-Fi upgrade in November 2016.

Teams and stadium owners like to say their technology improvements are intended to improve fan experience. The Red Bulls are no exception, but Peter Katic, senior director, IT and arena systems for the team, said there were other issues driving the Wi-Fi upgrade. Mostly, the team wanted technology that wouldn’t need to be supplemented or gotten rid of in a couple years. “We didn’t want to have to keep changing the cores or access points and doing site surveys,” Katic said. “We wanted something that would evolve with us, and after months of research we found the Cisco Meraki solution really fit the bill.”

Red Bull Arena is relatively new by sporting standards; it opened in 2010 on the banks of the Passaic River in New Jersey and seats 25,000. But the venue has never had fan-facing Wi-Fi. On the corporate side, the organization uses Aruba/Hewlett Packard for its wireless connectivity needs but keeps that network separate from fans.

A close-up look at a Wi-Fi antenna deployment, Credit: Red Bull Arena

In tandem with the new Wi-Fi installation, the Red Bulls bought Cisco switches for the entire venue’s networking requirements, and layered on the Meraki wireless gear. The new network, including 172 APs, went live this past March, Katic added.

The Red Bulls partnered with Safari Telecom for the heavy lifting part of the technology upgrade. “One of our biggest challenges was the I-beams and side beams on the sections of the lower bowl,” Katic said. Safari custom-built clamps and anchors for mounting the APs, since drilling through the beams wasn’t an option. “Safari did a great job working in subzero temperatures during the offseason, mounting this stuff and getting it activated for our first event,” an international mini-tournament, not a Red Bulls game, he said.

All the Meraki APs were mounted overhead, avoiding the extra cost of under-seat APs. “There wasn’t really a business need to mount APs underneath the seats to provide coverage to patrons, not to mention the additional resources and labor,” he explained, adding that Red Bull is a company that values aesthetics. “We’re a premium brand… even the color of the AP really fit into the stadium aesthetic.”

Red Bulls fans like iPhones

Editor’s note: This profile is an excerpt from our latest STADIUM TECH REPORT, our Summer 2017 issue that has in-depth profiles of network deployments at the Atlanta Braves’ new SunTrust Park, the Colorado Rockies’ Coors Field, and even a profile of a new Wi-Fi network for Westfield Century City Mall! DOWNLOAD YOUR FREE COPY of the report today!

The Red Bulls are already taking advantage of the Wi-Fi system’s native applications – things like analytics; total data downloads and uploads; identification of device types used by patrons as well as the websites they visit.

Another Wi-Fi AP deployment

“Facebook seems to be the king here, but fans are also on YouTube, Snapchat and Twitter,” Katic said. More than two-thirds of fans — 68% — use iPhones. “That’s an interesting statistic, especially for the app, which will need to be optimized for the iPhone,” he added.

So far, the highest number of connected users for a single game has been 3,200, with a peak rate of 2,400 simultaneous users. The arena’s Wi-Fi system is engineered with a take rate of 40 percent, and fans are getting upload and download speeds ranging from 40 to 80 Mbps during events, according to Katic.

“We’re always tweaking it, but the Wi-Fi performance has been better than we expected,” he said. At a recent match, fans downloaded about 490 GB of data and uploaded approximately 145 GB, according to figures Katic pulled off the Meraki dashboard, which he judged easy to use. “You don’t need to be an IT guru to get into the dashboard or run the analytics.”

There’s also a free API in the Cisco Meraki solution that allows the Red Bulls to add features and capabilities as needed. Though the Red Bulls haven’t tapped the API just yet, they’ve got lots of plans. “We intend to use the API for our splash page, target marketing, wayfinding, in-venue engagement, and loyalty and revenue-driving campaigns,” Katic said. “In this way, we really provide the fans what they want.”

There’s no companion app at the moment, but that’s likely to change. “We’re looking at it, but MLS is going to be launching a league-wide app for all the teams,” Katic added. It’s another smart way to build and deepen connection with Red Bull fans.

A good look at Wi-Fi deployments in the Red Bull Arena upper seating.
