Can virtualization help venues meet growing mobile capacity demands?

By Josh Adelson, director, Portfolio Marketing, CommScope

U.S. mobile operators reported a combined 50 terabytes of cellular traffic during the 2018 Super Bowl, nearly doubling over the previous year. In fact, Super Bowl data consumption has doubled every year for at least the past 6 years and it shows no sign of slowing down.

Clearly, fans love their LTE connections almost as much as they love their local team. Fans have the option for cellular or Wi-Fi, but cellular is the default connection whereas Wi-Fi requires a manual connection step that many users may not bother with.[1] The same dynamic is playing out on a smaller scale in every event venue and commercial building.

Whether you are a venue owner, part of the team organization or in the media, this heightened connectivity represents an opportunity to connect more with fans, and to expand your audience to the fans’ own social connections beyond the venue walls.

But keeping up with the demand is also a challenge. High capacity can come at a high cost, and these systems also require significant real estate for head-end equipment. Can you please your fans and leverage their connectedness while keeping equipment and deployment costs from breaking the capex scoreboard?

Virtualization and C-RAN to the rescue?

Editor’s note: This post is part of Mobile Sports Report’s new Voices of the Industry feature, in which industry representatives submit articles, commentary or other information to share with the greater stadium technology marketplace. These are NOT paid advertisements, or infomercials. See our explanation of the feature to understand how it works.

Enterprise IT departments have long since learned that centralizing and virtualizing their computing infrastructures has been a way to grow capacity while reducing equipment cost and space requirements. Can sports and entertainment venues achieve the same by virtualizing their in-building wireless infrastructures? To answer this question, let’s first review the concepts and how they apply to wireless infrastructure.

In the IT domain, virtualization refers to replacing multiple task-specific servers with a centralized resource pool that can be dynamically assigned to a given task on demand. Underlying this concept is the premise that, while each application has its own resource needs, at any given time only a subset will be active, so the total shared resource can be less than the sum of the individual requirements.

How does this translate to in-building wireless? Centralizing the base station function is known as C-RAN, which stands for centralized (or cloud) radio access network. C-RAN involves not only the physical pooling of the base stations into a single location — which is already the practice in most venues — but also digital architecture and software intelligence to allocate baseband capacity to different parts of the building in response to shifting demand.

C-RAN brings immediate benefits to a large venue in-building wireless deployment. The ability to allocate capacity across the venue via software rather than hardware adds flexibility and ease of operation. This is especially important in multi-building venues that include not only a stadium or arena but also surrounding administrative buildings, retail spaces, restaurants, hotels and transportation hubs. As capacity needs shift between the spaces by time of day or day of week, you need a system that can “point” the capacity to the necessary hot spots.

C-RAN can even go a step further to remove the head-end from the building campus altogether. Mobile network operators are increasingly deploying base stations in distributed locations known as C-RAN hubs. If there is a C-RAN hub close to the target building, then the in-building system can take a signal directly from the hub, via a fiber connection. Even if the operator needs to add capacity to the hub for this building, this arrangement gives them the flexibility to use that capacity in other parts of their network when it’s not needed at the building. It also simplifies maintenance and support as it keeps the base station equipment within the operator’s facilities.

For the building owner, this architecture can reduce the footprint of the on-campus head-end by as much as 90 percent. Once the baseband resources are centralized, the next logical step is to virtualize them into software running on PC server platforms. As it turns out, this is not so simple. Mobile baseband processing is a real-time, compute-intensive function that today runs on embedded processors in specialized hardware platforms. A lot of progress is being made toward virtualization onto more standard computers, but as of today, most mobile base stations are still purpose-built.

Perhaps more important for stadium owners is the fact that the base station (also called the signal source) is selected and usually owned by the mobile network operator. Therefore the form it takes has at most only an indirect effect on the economics for the venue. And whether the signal source is virtual or physical, the signal still must be distributed by a physical network of cables, radios and antennas.

The interface between the signal source and the distribution network provides another opportunity for savings. The Common Public Radio Interface (CPRI) establishes a digital interface that reduces space and power requirements while allowing the distribution network — the DAS — to take advantage of the intelligence in the base station. To leverage these advantages, the DAS also needs to be digital.

To illustrate this, consider the head-end for a 12 MIMO sector configuration with 4 MIMO bands per sector, as shown below. In this configuration a typical analog DAS is compared with a digital C-RAN antenna system, with and without a CPRI baseband interface. In the analog systems, points of interface (POIs) are needed to condition the signals from the different sources to an equal level before they are combined and converted to optical signals via an e/o (electric to optical) transceiver. In a digital system, signal conditioning and conversion from electric to digital is integrated into a single card, providing significant space saving.

* A typical analog system will require 8 POIs (4 MIMO bands per sector) and 2 o/e transceivers per sector resulting in 10 cards per sector. A typical subrack (chassis) supports up 10-12 cards, so a subrack will support 1 MIMO sector. For 12 MIMO sectors, 12 subracks are needed and each is typically 4 rack unit height. This results in a total space of 48 rack units.

* For a digital system[2] without CPRI, each subrack supports 32 SISO ports. Each MIMO sector with 4 MIMO bands will require 8 ports resulting in supporting 4 MIMO sectors per subrack. For 12 MIMO sectors, 3 subracks of 5 rack unit height each are needed resulting in total space of 15 rack units.

* For a digital system with CPRI, each subrack supports 48 MIMO ports. Each MIMO sector with 4 MIMO bands will require 4 ports resulting in 12 MIMO sectors per subrack. For 12 MIMO sectors, only 1 subrack of 5 rack unit height is needed resulting in total space of 5 rack units.

One commercial example of this is Nokia’s collaboration with CommScope to offer a CPRI interface between Nokia’s AirScale base station and CommScope’s Era C-RAN antenna system. With this technology, a small interface card replaces an array of remote radio units, reducing space and power consumption in the C-RAN hub by up to 90 percent. This also provides a stepping-stone to future Open RAN interfaces when they become standardized and commercialized.

The Benefits in Action — A Case Study

Even without virtualization, the savings of digitization, C-RAN and CPRI at stadium scale are significant. The table below shows a recent design that CommScope created for a large stadium complex in the U.S. For this, we compared 3 alternatives: traditional analog DAS, a digital C-RAN antenna system with RF base station interfaces, and a C-RAN antenna system with CPRI interfaces. Digital C-RAN and CPRI produce a dramatic reduction in the space requirements, as the table below illustrates.

The amount of equipment is reduced because a digital system does in software what analog systems must do in hardware, and CPRI even further eliminates hardware. Energy savings are roughly proportional to the space savings, since both are a function of the amount of equipment required for the solution.

Fiber savings, shown in the table below, are similarly significant.

The amount of fiber is reduced because digitized signals can be encoded and transmitted more efficiently.

But these savings are only part of the story. This venue, like most, is used for different types of events — football games, concerts, trade shows and even monster truck rallies. Each type of event has its own unique traffic pattern and timing. With analog systems, re-sectoring to accommodate these changes literally requires on-site physical re-wiring of head-end units. But with a digital C-RAN based system it’s possible to re-sectorize from anywhere through a browser-based, drag and drop interface.

The Bottom Line

It’s a safe bet that mobile data demand will continue to grow. But the tools now exist to let you control whether this will be a burden, or an opportunity to realize new potential. C-RAN, virtualization and open RAN interfaces all have a role to play in making venue networks more deployable, flexible and affordable. By understanding what each one offers, you can make the best decisions for your network.

Josh Adelson is director of portfolio marketing at CommScope, where he is responsible for marketing the award-winning OneCell Cloud RAN small cell, Era C-RAN antenna system and ION-E distributed antenna system. He has over 20 years experience in mobile communications, content delivery and networking. Prior to joining CommScope, Josh has held product marketing and management positions with Airvana (acquired by CommScope in 2015) PeerApp, Brooktrout Technology and Motorola. He holds an MBA from the MIT Sloan School of Management and a BA from Brown University.

1: 59 percent of users at the 2018 Super Bowl attached to the stadium Wi-Fi network.
2: Dimensioning for digital systems is based on CommScope Era.

AT&T beefs up ski resort reception with stealthy DAS

AT&T DAS antenna stand (right) near the American Eagle lift at Copper Mountain. Credit all photos: Paul Kapustka, MSR (click on any photo for a larger image)

In order to improve cellular reception at the Copper Mountain ski area, AT&T this winter installed a stealthy seven-antenna DAS in several base-area locations, including inside ski-lodge buildings and inside a rooftop cupola.

According to Quin Gelfand, a senior real estate and construction manager for AT&T’s Antenna Solutions Group, the mountain had previously been served only by a single macro tower located up near the slopes of the popular Colorado resort, which is located just off the I-70 Interstate between Frisco and Vail.

On heavy skier-visit days, Gelfand said, the macro tower recently caused some “capacity concerns,” leading AT&T to design a DAS solution for the several base areas at Copper Mountain. In addition to just being saturated by demand, Gelfand said the single macro antennas often didn’t provide strong signals inside buildings at the base areas.

“In a lot of areas around the resort, there were low bars for LTE,” Gelfand said.

AT&T’s Quin Gelfand shows off the main head end DAS gear rack.

But on Feb. 23 this year, that situation changed for AT&T cellular customers, as the DAS went live and immediately started moving lots of cellular traffic. By the time of our visit in early April, Gelfand said the DAS installation (which has the capacity equivalent of a single large macro tower) had already seen more than 7 terabytes of data moved, averaging about 175 GB per day. Like at many Colorado ski areas, March is a busy month at Copper with lots of spring break skiers and locals driving up on weekends from Denver.

Hiding antennas in a cupola

Brad Grohusky, senior IT manager for Copper Mountain, said AT&T approached the resort a couple of years ago to discuss the idea of a DAS. “When we had a dense population of guests, it was pretty easy to saturate a signal,” Grohusky said.

On weekends, Grohusky said Copper could often see as many as 10,000 guests, and might even see as many as 14,000 visitors on popular days or holidays. Wireless communications, he said, could get even more stress if the weather turned nasty or cold, driving more people inside buildings.

DAS antenna (upper top left) in Copper Station lodge

Starting from an existing telecom service room located in an underground garage, AT&T ran fiber this past offseason to three different antenna locations. The closest and most obvious is a three-antenna stand near the “Burning Stones” gathering area and the American Eagle chairlift base. As one of the resort’s main first chairs the American Eagle often has crowds at its base, and the Burning Stones area is a small clearing between the slopes and the base area buildings that is used often for concerts and other public gatherings.

“There was lots of digging last summer,” said Grohusky of the fiber-trenching effort, which gained some extra time thanks to a warmer-than-usual fall that kept the snow at bay. “We took advantage of that extra week,” Grohusky said.

If the American Eagle-area antennas are in plain sight, the two antennas at the Union Creek Schoolhouse base area to the west would be impossible to find if you didn’t know where they were; on the roof of a building AT&T built custom-designed baffling for a rooftop cupola that completely hides the antennas while allowing cellular signals to pass through.

“You would never know the antennas were up there,” Grohusky said. “AT&T really accomodated our architecture there.”

Closer look at DAS tower near American Eagle lift

Back farther to the east, two more antennas were located at the top windows of the Copper Station lodge building, pointed outward to cover the lift base areas and the condos and other buildings in that area. According to Gelfand AT&T used Nokia RAN gear as well as Corning fiber equipment, CommScope cabling components and antennas from JMA Wireless in the deployment. The DAS is powered by a 100 Mbps fiber link from CenturyLink, and supports three cellular bands — 700 MHz, AWS and PCS, according to Gelfand.

Even though ski season is all but over, the network will still get use in the non-snowy months as Copper Mountain, like many Colorado resorts, has an active summer schedule of on-mountain activities. The resort also has a limited free public Wi-Fi network in certain base area buildings, including in and around the Starbucks location right next to the Burning Stones area. Gohusky said there are no current plans to expand the Wi-Fi, and also said that none of the other major cellular carriers are planning to add any of their own DAS deployments.

But for AT&T customers, Grohusky said connectivity is vastly improved. “The feedback has been great,” he said. “Connectivity used to be poor inside buildings, but now it’s great.”

Look back toward the Burning Stones gathering area, near American Eagle lift

Union Creek Schoolhouse building — cupola with AT&T antennas is the one closest to ski hill

JMA Wireless antenna mounted high up inside Copper Station lodge

CommScope gear inside the Copper Station node equipment room

Corning optical gear inside the Copper Station node equipment room

Copper Station lodge building (with DAS antennas) on far right, showing proximity to eastern base area
